Model No. |
|
Camera |
Sensor |
1/2.8" 5MegapixelCMOS Sensor |
Video System |
HDMI |
NDI|HX |
3G-SDI |
USB |
1920x10800p60/50/30/25
1280x720p60/50/30/25
1920x1080i60/50 |
Main Steam:
1920x1080p30
1280x720p30
Sub Steam:
1280x720@30
1024x576@30
640x360@30 |
1920x1080p60/50/30/25
1280x720p60/50/30/25
1920x1080i60/50 |
USB 3.0:
1920x1080p60/50/30/25
1280x720p60/50/30/25
1024x576p30
USB 2.0:
1024x576p30,960x540p30
640x360p30,352x288p30 |
Zoom |
12x optical zoom + 2x digital zoom |
View Angle |
6.3°(wide) - 72.5°(Tele) |
Focal Length |
f=3.92(wide) - 47.32mm(Tele) |
Preset |
10 via remote controller; 128 via serial port; preset precision:0.1° |
Pan Rotation Angle |
- 170° - +170° |
Tilt Roation Angle |
- 30° - + 90° |
Pan Rotation Speed |
0° - 120° /s |
Tilt Rotation Speed |
0° - 80° /s |
Control Port |
NDI|HX RS232 / RS485 |
Video Port |
NDI|HX/3G-SDI/HDMI/USB3.0 |
Network Speed |
1000M |
Noise Reduction |
2D & 3D |
SNR |
Above 50dB |
Minimum Lux |
0.01Lux |
White Balance |
Auto/Manual/Auto Tracking/OnePush/Indoor/Outdoor |
Anti Flicker |
50Hz/60Hz/OFF |
D/N Mode |
Supported |
Gamma |
Supported |
Mirror Image |
Supported |
Image Flip |
Supported |
Iris |
Auto/Manual |
Electric Shutter |
Auto/Manual |
BLC |
Atuo/Manual |
Focus |
Auto/Manual |
Video Encoding |
H.264/H.265 |
Bit Rate Control |
Variable BitRate, Constant Bit Rate |
Video Bit Rate |
1024Kbps - 20480Kbps |
Frames |
50HZ: 1fps - 30fps; 60HZ: 1fps - 30fps |
IP Protocol |
TCP/IP, HTTP,RTSP, RTMP, Onvif, DHCP,VISCA over IP(TCP&UDP),HTML5 |
POE |
Supported |
Power |
DC12V,2A |
Dimension |
220mm x 173mm x 190mm |
Net Weight |
1.25KGS(2.8LBS) |
